In the previous post we saw how we can embed a Superset dashboard in a webpage using a Flask app. In this post we’ll look at creating indexes on the tables that are stored in Pinot. We’ll look at the various types of indexes that can be created and then create indexes of our own to speed up the queries.

Getting started

Very briefly, a database index is a data structure that improves retrieving data from the tables. It is used to quickly find the rows that we’re interested in without having to scan the entire table. Pinot supports different types of indexes that can be used to speed up different types of queries. Knowing the access patterns of the queries helps us decide which indexes we’d like to create. We’ll quickly look at each type of index that Pinot provides, write a few queries, and then create indexes to speed them up. Let’s start by looking at the various index types that are available in Pinot.

Pinot supports the following types of indexes — bloom filter index, forward index, FST index, geospatial index, inverted index, JSON index, range index, star-tree index, text search index, and timestamp index. In the sections that follow, we’ll look at how to create an inverted index, and a range index to speed up our queries. Let’s start with the inverted index.

Let’s say we’d like to find out the sum of the amounts of orders placed on January 1st. One way to write this query would be to convert the created_at time to a date on the fly. This would require us to look at every row we have in the table and compare it against the date we’re looking for. Another way to write this query would be to convert created_at to a date during ingestion time and create an inverted index on it. Creating an inverted index would store a mapping of each date to the row IDs with the same date. This will enable us to filter only those rows which have the date we’re looking for instead of having to look at each one of them.

We’d have to update our table and schema for the orders table. We’ll start by adding a column to our schema definition which will store the date as a string.

1
2
3
4

{
  "name": "date",
  "dataType": "STRING"
}

Next, we’ll convert the created_at time to a date and store it in the date column. To do this, we’ll create a field-level transformation in the table definition.

1
2
3
4

{
  "columnName": "date",
  "transformFunction": "toDateTime(created_at, 'yyyy-MM-dd')"
}

Next, we’ll enable the inverted index on the date column by adding the following to the table definition.

1
2
3
4
5
6
7

{
  "tableIndexConfig": {
    "invertedIndexColumns": [
      "date"
    ],
    "createInvertedIndexDuringSegmentGeneration": true
}

Once we PUT these configs, we’ll reload the segments so that the index is created. We can now write our query in the Pinot console.

1
2
3
4

SELECT "date", SUM(amount) as total
FROM orders
WHERE "date" = '2024-01-01'
GROUP BY 1;

We can verify that the index was used by looking at the explain plan for the query.

1
2
3
4
5

EXPLAIN PLAN FOR
SELECT "date", SUM(amount) as total
FROM orders
WHERE "date" = '2024-01-01'
GROUP BY 1;

This produces the following result.

Looking at the explain plan, we find the following line. It tells us that the index was used to look up the date ‘2024-01-01’

1

FILTER_SORTED_INDEX(indexLookUp:sorted_index,operator:EQ,predicate:date = '2024-01-01')

Let’s modify the query slightly and look for the daily total for the last 90 days. It looks as follows.

1
2
3
4
5

SELECT "date", SUM(amount) as total
FROM orders
WHERE created_at >= ago('P90D')
GROUP BY 1
ORDER BY 1

The ago() function takes as argument a duration string and returns milliseconds since epoch. We compare it against created_at, which is also expressed as milliseconds since epoch, to get the final result. Let’s look at the explain plan for the query.

We find the following line which indicates that an index was not used.

1

FILTER_FULL_SCAN(operator:RANGE,predicate:created_at >= '1728886039203')

We can improve the performance of the query by using a range index which allows us to efficiently query over a range of values. This helps us speed up queries which involve comparison operators like less than, greater than, etc. To create a range index, we’ll have to update the table definition and specify the column on which we’d like to create the index. We’ll add the following to the table definition.

1
2
3
4
5
6

{
  "tableIndexConfig": {
    "rangeIndexColumns": [
      "created_at"
    ]
}

Like we did previously, we’ll PUT this config and reload the segments. We’ll once again look at the explain plan for the query above.

We now find the following line which indicates that the range index was used.

1

FILTER_RANGE_INDEX(indexLookUp:range_index,operator:RANGE,predicate:created_at >= '1728887647851')

This was a quick overview of using indexes to speed up queries on Pinot. We looked at the inverted index and the range index. In the next post, we’ll look at the star-tree index which lets us compute pre-aggregations on columns and speeds up the result of operations like SUM and COUNT. We’ll also look at stream processing to generate new events from the ones emitted by Debezium.

In the previous post we looked at how to visualize our data using Superset. In this post we’ll look at embedding our dashboards. Embedding allows us to display a dashboard outside of Superset and within a webpage. This lets us blend analytics seamlessly into the user’s workflow. We’ll tweak a few Superset settings to allow us to embed a dashboard, and then build a Flask application which will render it in a webpage. We’ll also look at row-level security which lets us limit a user’s access to only those rows that they are allowed access to.

Getting started

Let’s say we’d like to create a dashboard that consists of a line chart and a table. The line chart plots the number of orders the user has placed daily. The table shows the cafes where the user frequently orders from. We’ll start by writing a query which will enable us to create the line chart. This will be stored as a view so that rendering the data produces realtime results. The query is as follows.

1
2
3
4
5
6

CREATE VIEW hive.views.daily_orders_by_users AS
SELECT user_id,
       CAST(FROM_UNIXTIME(CAST(created_at AS DOUBLE) / 1e3) AS DATE) AS dt,
       COUNT(*) AS count
FROM pinot.default.orders
GROUP BY 1, 2;

Next, we’ll create the view which will tell us the cafes the user orders from. It is as follows.

1
2
3
4
5
6
7
8
9
10

CREATE VIEW hive.views.frequent_cafes AS
SELECT o.user_id,
       c.name AS cafe,
       COUNT(*) AS count,
       RANK() OVER(PARTITION BY o.user_id ORDER BY COUNT(*) DESC) AS rank
FROM pinot.default.orders AS o
  INNER JOIN pinot.default.cafe AS c
  ON CAST(o.cafe_id AS VARCHAR) = c.id
GROUP BY 1, 2
ORDER BY 1 ASC, 3 DESC;

Once the views have been constructed, we can use them in Superset to build our dashboard. To enable dashboard embedding, we must first update some Superset settings. If you have any Superset containers running from the last post, start by shutting them down. Then, run the following command to remove any Docker images linked to Superset; we’ll rebuild it with the new settings.

1

docker images | grep superset | awk '{print $3}' | xargs docker rmi

Let’s begin editing the settings. Navigate to the superset directory within the superset repository and open the config.py file. This contains the configuration that will be used by the Superset application when it runs. We’ll edit this line-by-line and see why these changes are required. First, we’ll disable the Talisman library used by Superset. Find the variable TALISMAN_ENABLED and update it to the following.

1

TALISMAN_ENABLED = False

Talisman is a Python library that protects Flask against some of the common web application security issues. Since we’ll be running this locally over HTTP, we can disable this to allow the embedded dashboard to render within the webpage. Next, we’ll disable CSRF protection. Again, all of these settings are to make things run locally over an HTTP connection. You should let these be for production deployment. Find the variable WTF_CSRF_ENABLED and set it to False.

1

WTF_CSRF_ENABLED = False

Next, enable dashboard embedding. This is disabled by default. Find the EMBEDDED_SUPERSET variable and set it to True.

1

"EMBEDDED_SUPERSET": True

Finally, we’ll elevate the permissions of the Guest user to enable us to render dashboards in an iframe. Set GUEST_ROLE_NAME to Gamma.

1

GUEST_ROLE_NAME = "Gamma"

Superset has some predefined roles with permissions attached to them. The Gamma role is the one for data consumers and has limited access. Assigning the Gamma role to the guest user lets us embed the dashboard within a web application. As we’ll see shortly, we’ll generate a guest token which we’ll use when embeding a dashboard.

With these changes made, we can rebuild the Superset images. Run the following command to build them.

1

TAG=4.1.1 docker compose -f docker-compose-non-dev.yml build

This will take a while to build. In the meantime, we’ll start writing our Flask application. It’ll be a simple application that renders a Jinja template. In that template we’ll add the code to display the embedded dashboard. Let’s see what the template looks like.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28

<title>Dashboard</title>

<style>
  body, div {
      width: 100vw;
      height: 100vh;
  }
</style>

<div id="chart"></div>

<script src="https://unpkg.com/@superset-ui/embedded-sdk"></script>
<script>
  supersetEmbeddedSdk.embedDashboard({
      id: '{{ chart_id }}',
      supersetDomain: 'http://192.168.0.103:8088',
      mountPoint: document.getElementById("chart"),
      fetchGuestToken: () => "{{ guest_token  }}",
      dashboardUiConfig: {
        hideTitle: true
      },
      iframeSandboxExtras: []
  })

  // This is a hack to make the iframe bigger.
  document.getElementById("chart").children[0].width="100%";
  document.getElementById("chart").children[0].height="100%";
</script>

Let’s unpack what’s going on. The embedded dashboard is rendered within an iframe and we need a container element to hold it. This is what the div is for; it’ll hold the iframe.

Next, we load the Superset embed SDK from the CDN. This make the supersetEmbededSdk variable globally available. We call the embedDashboard method on it to embed the dashboard. This method takes an object which contains the information needed for embedding. The first piece of informaton we pass is the id of the chart. As we’ll see shortly, we get this from the Superset UI. We’re using a template variable here and we’ll replace it with its actual value when we render the webpage.

Next, we specify the address of our Superset instance in the supersetDomain field. Here I’ve used the IP address of my local machine to point to the Docker containers running Superset.

Next, we specify the mount point. The mountPoint is the element within the page where the chart will be rendered. We’re retrieving the div using its ID.

Next, we specify the fetchGuestToken function. This function retrieves the guest token from the backend. Since we’re rendering the template from a Flask application, we’ll fetch the guest token on the servier side. Therefore, we simply return the guest token from the function. We’ve used a Jinja variable guest_token which we’ll replace with its actual value when we render the template.

Next, we specify some configuration information. In our example, we’ve hidden the title of the dashboard.

Finally, we increase the size of the iframe so that it fills the screen.

Having written the template, we’ll move on to writing the Flask web application. It’s a single file with one endpoint to render the chart. We’ll write functions to see how we can log into Superset using its API and then fetch a guest token. The complete code for the app is given below.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53

from flask import Flask, render_template
import requests

app = Flask(__name__)
chart_id = "2e8635f3-349a-4c91-bb6e-ff4883a543cc"


def get_access_token() -> str:
    json = {"username": "admin", "password": "admin", "provider": "db", "refresh": True}

    response = requests.post(
        "http://192.168.0.103:8088/api/v1/security/login",
        headers={
            "Content-Type": "application/json",
            "Accept": "application/json",
        },
        json=json,
    )

    response.raise_for_status()
    return response.json()["access_token"]


def get_guest_token(user_id: int) -> str:
    access_token = get_access_token()

    response = requests.post(
        "http://192.168.0.103:8088/api/v1/security/guest_token",
        headers={
            "Content-Type": "application/json",
            "Accept": "application/json",
            "Authorization": f"Bearer {access_token}",
        },
        json={
            "resources": [{"id": chart_id, "type": "dashboard"}],
            "rls": [{"clause": f"user_id={user_id}"}],
            "user": {"first_name": "...", "last_name": "...", "username": "..."},
        },
    )

    response.raise_for_status()
    return response.json()["token"]


@app.route("/chart/<int:user_id>")
def chart(user_id: int):
    guest_token = get_guest_token(user_id)
    return render_template("chart.html", guest_token=guest_token, chart_id=chart_id)


if __name__ == "__main__":
    app.run(host="0.0.0.0", port=5555, debug=True)

Let’s step through the code. The chart_id is the unique identifier for the chart we’re trying to embed. As we’ll see shortly, this comes from the Superset UI.

Next, we define the get_access_token function which retrieves an access token. To get this, we need to log into Superset. We use the default username and password which we POST to the login endpoint and extract the token from the JSON that’s returned. This token lets us fetch a guest token which is required for embedding the dashboard.

Next, we define the get_guest_token function which retrieves the guest token. It takes the ID of the user as an argument so that it can apply row-level security to the dataset that powers the dashboard. Row-level security, often abbreviated as RLS, is a mechanism which restricts a user’s access to only those rows that they have the permission to access. If we look at the view we’ve created, it contains the data for all the users. Applying row-level security allows us to display only those rows which pertain to the given user. The rls field in the JSON body contains the clause which limits the access of the user. It is applied as a part of the WHERE clause and filters the rows in the dataset. The resources field contains the ID of the chart that we’d like to embed. The user field contains the details of the guest user.

Next, we define the chart function which actually renders the tempalte. The template is rendered by calling the render_template function which takes the guest token and chart ID as arguments. This generates the final HTML which is returned to the user.

We’ll run this app in a separate terminal by executing the following command.

1

python run_app.py

After waiting for a while to let the Superset images build, we can go ahead and bring up its containers.

1

TAG=4.1.1 docker compose -f docker-compose-non-dev.yml up -d

After opening the Superset UI, we’ll begin by creating a dashboard. We’ll add a chart to the dasboard which is backed by the daily_orders_by_users view which we created earlier. We’ll add an area chart where we have date on the x-axis and the count on the y-axis with the ID of the user being the dimension. The screenshot below shows what it looks like.

The chart looks cluttered because it is displaying the data of every user. When we embed this chart, we’ll rely on row-level security to display the chart that only belongs to a particular user. Similarly, we’ll add a table backed by the frequent_cafes view and display it in the dashboard. Remember that the filtering is applied to the dataset backing the chart. This means that we can create the table and exclude the user_id column from display.

Having added all our charts to the dashboard, we can embed it in the webapp. Begin by saving the dashboard. Then, click on the three dots on the top-right hand and click “Embed dashboard”. You should see a dialog box pop up which allows you to list the domains from which the embedded dashboard can be accessed. We’ll leave this empty to allow embedding from all domains and click “Enable Embedding”. From the next dialog box, we’ll copy the ID of the dashboard and then click the X button on the top-right hand to close it.

We’ll replace the chart_id variable in our web application and then run it. It will start a Flask application that listens on port 5555. We’ll navigate to http://localhost:5555/1 which will display the chart and the table for the user with ID 1. The embedded dashboard will apply the row-level security clause for this user ID and only display their data. The dashboard looks as follows.

That’s it. That’s how to embed a Superset dashboard.

In the previous post we saw how we can use Airflow to create datasets on top of the data that’s stored in Pinot. Once a dataset is created, we may need to present it as a report or a dashboard. In this post we’ll look at how to use Superset to create visualizations on top of the datasets that we’ve created. We’ll create a dashboard to display the daily change in the number of orders placed each day.

Getting started

In an earlier post I’d written about how to run Superset locally. In a nutshell, running Superset using Docker compose requires cloning the repository and checking out the version of the project you’d like to run. In that post I’d also shown how to install additional packages so that we can add the ability to connect to another database. For the sake of brevity, I’ll simply repeat the steps here and refer you to the earlier post for more details.

Let’s start by cloning the repo and navigating to it.

1
2

git clone https://github.com/apache/superset.git --depth 1
cd superset

Next, we’ll checkout the git repository to a specific tag so that we can build from it.

1

git checkout 4.1.1

Next, we’ll add the Python package which will let us connect to Pinot.

1

echo "pinotdb" >> ./docker/requirements-local.txt

Finally, we’ll bring up the containers for this specific tag.

1

TAG=4.1.1 docker-compose -f docker-compose-non-dev.yml up -d

This will build the Docker images for Superset and run them as containers. Once the containers are running, Superset will be available on http://localhost:8088. You can use admin as both the username and password to log in. Now that we’re logged in, we can begin creating charts and dashboards. Let’s start by connecting to Trino.

Click on “Settings” on the top-right corner. Click on “Database Connections”. Finally, click on “+ Database”. You should see the following screen pop up.

From the supported databases, select “Trino”. Once selected, you’ll be asked to enter the connection string to connect to it. Since the Superset Docker containers are running seperately from the ones where Trino is running, we’ll have to use the IP address of the local machine to make the connection between Superset and Trino. Depending on your operating system, the steps may vary. Go ahead and find the IP address of your machine. Let’s continue with my machine. We’ll have to enter the connection string that SQLAlchemy expects. It looks as follows.

1

trino://admin:@192.168.0.103:9080

Notice how we’ve specified admin as the user and a blank password. I’m also specifying the port since I’ve mapped Trino’s port 8080 to 9080 locally. Once we’ve entered the details, we can click on “Test Connection” to make sure we’re able to connect. Finally, if the connection succeeds, we’ll click on “Connect” to save the connection. We can now proceed to creating charts and dashboards.

Click on “Dashboards” on the top-left and then click on “+ Dashboard”. This will create a new draft dashboard in which we’ll visualize datasets. Change its name to “Orders and click “Save”. You should see a screen similar to the one shown below.

Click on “Create a new chart” button in the middle of the screen. From there, click on “Add a dataset”. Every chart needs to be associated with a dataset. We’ll create them based on the ones we’ve stored in Trino. You should see the following screen.

From the drop down on the left, select “Trino” as the database. Select the “views” schema. Finally, select “daily_orders” as the table. Once done, click on “Create Dataset and Create Chart” option on the bottom-right. In the screen that shows, select “Area Chart” and click on “Create New Chart”. This screen is shown below.

Once on the screen to create the chart, we’ll add the dt column to the X-axis and SUM(pct) to the Y-axis. Since there’s only one value for each day, SUM will return the same value. Clicking on “Update Chart” on the bottom causes a query to be fired to Trino and the result to be rendered as a line chart. It looks as follows.

Click on “Save” on the top-right. Give the chart a name and associate it with the dashboard we just created. It’ll take you to the dashboard with the chart rendered in it. Clicking on “Edit Dashboard” will allow you to change the size of the chart. Go ahead and increase its width. Saving the chart will make your dashboard look as follows.

At this point, we can create more datasets and charts. I’ve created two more - one for displaying the data for the line chart as a table, and another for displaying the top customers. My final dashboard looks as follows.

The table and the line-chart are created from a view we’d created on top of Trino. Superset caches the results of the query for faster rendering. We can refresh the charts to see the latest data. Clicking on the three dots on the top-right of any chart will show the “Force refresh” option. Clicking on it will cause Superset to query Trino again to fetch the latest data. Since Pinot is getting updated in realtime and we have a view backing the chart, we’ll get the realtime numbers in the dashboard. We can make this happen automatically. Let’s go ahead and do that.

Click on “Edit dashboard”. Click on the three dots on the top-right and click on “Set auto-refresh interval”. In the pop-up that shows, select a frequency. Click “Save” to save this setting. Click “Save” one more time to save the dashboard. This will make the chart update in realtime without requiring the user to manually refersh it.

That’s it. That’s how you can create realtime dashbord on top of Pinot using Superset and Trino.

In the previous post we looked at how to query Pinot. We queried it using its REST API, the console, and Trino. In this post we’re going to look at how to use Apache Airflow to periodically create datasets on top of the data that’s been stored in Pinot. Creating datasets allows us to reference them in data visualization tools for quicker rendering. We’ll leverage Trino’s query federation to store the resultant dataset in S3 so that it can be queried using the Hive connector.

Getting started

Let’s say that the marketing team wants to run email campaigns where the users who actively place orders are given a promotional discount. The dataset they need contains the details of the user like their name and email so that the communication sent out can be personalised. We can write the following query in the source Postgres database to see what the dataset would look like.

1
2
3
4
5
6
7
8
9
10
11
12

SELECT
    u.id,
    u.first_name,
    u.email,
    COUNT(*) AS COUNT
FROM
    public.user AS u
    INNER JOIN orders AS o ON u.id = o.user_id
WHERE
    o.created_at >= NOW() - INTERVAL '30' DAY
GROUP BY 1, 2, 3
ORDER BY 4 DESC;

This gives us the following result.

1
2
3
4
5
6
7

| id | first_name | email                       | count |
|----|------------|-----------------------------|-------|
|  5 | Michelle   | gilljasmine@example.com     |  4906 |
|  1 | Alejandra  | wilcoxstephanie@example.org |  4904 |
|  3 | Hailey     | james97@example.com         |  4877 |
|  4 | Michelle   | ivillanueva@example.com     |  4872 |
|  2 | Brandon    | julie33@example.com         |  4846 |

For us to create this dataset using Trino, we’ll have to ingest the user table into Pinot. Like we did in the earlier posts, we’ll use Debezium to stream the rows. We’ll skip repeating the steps here since we’ve already seen them. Instead, we’ll move to writing the query in Trino. Once we’ve written the query, we’ll look at how to use Airflow to run it periodically. I’ve also updated the orders table to extract the user_id column out of the source payload. Let’s translate the query written for Postgres to Trino.

1
2
3
4
5
6
7
8
9
10

SELECT u.id,
       u.first_name,
       u.email,
       COUNT(*) AS count
FROM pinot.default.user AS u
     INNER JOIN pinot.default.orders AS o
     ON o.user_id = u.id
WHERE FROM_UNIXTIME(CAST(o.created_at AS DOUBLE) / 1e3) >= NOW() - INTERVAL '30' DAY
GROUP BY 1, 2, 3
ORDER BY 4 DESC;

We saw earlier that we’d like to save the result of this query so that the marketing team could use it. We can do that by storing the results in a table created using the above SELECT statement. Let’s create a schema in Hive called datasets where we’ll store the results. The following query creates the schema.

1
2
3
4

CREATE SCHEMA hive.datasets
WITH (
    "location" = 's3://apache-pinot-hive/datasets'
);

We can now create the table using the above SELECT statement.

1
2
3
4
5
6
7
8
9
10

CREATE TABLE hive.datasets.top_users AS
SELECT u.id,
       u.first_name,
       u.email,
       COUNT(*) AS count
FROM pinot.default.user AS u
     INNER JOIN pinot.default.orders AS o
     ON o.user_id = u.id
WHERE FROM_UNIXTIME(CAST(o.created_at AS DOUBLE) / 1e3) >= NOW() - INTERVAL '30' DAY
GROUP BY 1, 2, 3;

We can now query the table using the query that follows.

1
2

SELECT *
FROM hive.datasets.top_users;

Having seen how to create datasets as tables using Trino CLI, let’s see how we can do the same using Airflow. Let’s say that the marketing team requires the data to be regenerated everyday. We can schedule an Airflow DAG to run daily to recreate this dataset. Briefly, Airflow is a task orchestrator. An orchestrator allows creating and executing workflows expressed as directed acyclic graphs (DAGs). Each workflow consists of multiple tasks, which form the nodes in the graph, and edges between the tasks indicate the directionality.

We’ll create a workflow which recreates the dataset daily. In a nutshell, the workflow first drops the older table and then recreates a newer one. This is because the Trino connector does not allow creating or replacing table as an atomic operation. We’ll leverage Airflow’s SQL operator and templating mechanism to create and execute queries. The following shows the files and folders we’ll be working with as we create the DAG.

1
2
3
4
5
6
7
8
9

$ tree airflow/dags
airflow/dags
├── __init__.py
├── create_top_users_dataset.py
└── sql
    ├── common
    │   ├── drop_table.sql
    └── datasets
        └── top_users.sql

Let’s begin with the drop_table.sql query. This is a templated query which allows dropping a table. Writing queries as templates allows us to leverage the Jinja2 templating engine that comes with Airflow. We can create queries depending on the parameters passed to the operator. This allows reusing the same template across multiple tasks. The variables are enclosed in two pairs of braces and the name of the variable is written between them. The content of the file is shown below.

1

DROP TABLE IF EXISTS {{ params.name }}

As we’ll see shortly, we’ll pass parameters to the Airflow task executing this query which are available in the params dictionary in the template. In the query above, we’d have to pass the name variable which contains the name of the table we’d like to drop. The top_users.sql file contains the same query we’ve seen above so we’ll move on to setting up the DAG.

The DAG is written in the file create_top_users_dataset.py and contains two tasks. First, to drop the table, which uses the templated query above. Second, to create the dataset. Both of these tasks use the SQLExecuteQueryOperator. Its parameters include a connection ID, which is used to connect to the database, the path to the SQL file containing the templated query to execute, and the values for the parameters. The contents of the file are shown below.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29

import pendulum
from airflow.providers.common.sql.operators.sql import SQLExecuteQueryOperator

from airflow import DAG

dag = DAG(
    dag_id="create_daily_datasets",
    catchup=False,
    schedule="@daily",
    start_date=pendulum.now("GMT"),
)

drop_table = SQLExecuteQueryOperator(
    task_id="drop_top_users",
    conn_id="trino",
    params={"name": "hive.datasets.top_users"},
    sql="sql/common/drop_table.sql",
    dag=dag,
)

create_table = SQLExecuteQueryOperator(
    task_id="create_top_users",
    conn_id="trino",
    sql="sql/datasets/top_users.sql",
    dag=dag,
)

# -- Dependencies between tasks
drop_table >> create_table

We define the DAG in line 6 and specify that it will execute daily. Line 13 and 21 define the tasks within the DAG. The first task drops the table, if it exists. The second task creates the table again. On line 29 we define the relationship between the tasks. Both of the tasks are of type SQLExecuteQueryOperator. This task allows executing arbitrary SQL queries by connecting to a database. The connection to the database is specified as the conn_id; we’ve specified it as trino. As we’ll see next, we need to create the connection using the Airflow console. Once we create the connection, we can execute the DAG.

Airflow UI is available on http://localhost:8080. From there we’ll click on ‘Admin’ up top, and then ‘Connections’. From there we’ll click on the ‘+’ icon to create a connection. The screenshot below shows what we need to fill in to make the connection. In my setup, Trino runs with the hostname trino and you’ll have to replace this to match what you have. Once the details are entered, we’ll click the ‘Save’ button at the bottom to create the connection.

Finally, we can trigger the DAG. We’ll click on the ‘DAGs’ option on top left side of the screen. This will show us the list of DAGs available. From there, we’ll click the play button for the create_daily_datsets DAG. This will trigger and run the DAG. We’ll wait for the DAG to finish running. Assuming everything works correctly, we will have created a table in S3. Leaving the DAG in the enabled state causes it to run on the specified schedule; in this case it is daily. As the DAG continues to run, it’ll create and recreate the table daily.

That’s it on orchestrating tasks to create datasets on top of Pinot.

In the previous post we looked at nullability and how Pinot requires that a default value be specified in place of an actual null. In this post we’ll begin looking at how to query data stored in Pinot. We’ll begin by querying Pinot using its API and query console. Then, we’ll query Pinot using Trino. We’ll use Trino’s query federation capability to create views and tables on top of the data that’s stored in Pinot.

Getting started

Pinot provides an SQL interface for writing queries that’s built on top of the Apache Calcite query parser. It ships with two query engines - the single-stage engine called v1 and the multi-stage engine called v2. The single-stage engine allows writing simpler SQL queries that do not involve joins or window functions. The multi-stage query engine allows more complex queries involving joins on distributed tables, window functions, common table expressions, and much more. It’s optimized for in-memory processing latency. Queries can be submitted to Pinot using the query console, REST API, or Trino. When querying Pinot using either the API or query console, we need to explicitly enable the multi-stage engine.

We’ll begin by writing SQL queries and submitting them first using the API and then using the query console. For queries that require a lot of data shuffling or data that spills to disk, it is recommended to use Presto or Trino. Let’s start by writing a simple SQL query that retrieves the user agent from the orders table. The SQL query to do this is given below.

1

SELECT user_agent FROM orders LIMIT 1;

We’ll create a file called query.json which contains the payload that we’ll POST to Pinot. It contains the SQL query and options to indicate to Pinot that we’d like to use the multi-stage engine to execute the query. The content of the file is given below.

1
2
3
4
5

{
    "sql": "SELECT user_agent FROM orders LIMIT 1;",
    "trace": false,
    "queryOptions": "useMultistageEngine=true"
}

We can now POST this payload to the appropriate endpoint using curl.

1

curl -s -d @query.json localhost:9000/sql | jq ".resultTable"

The response is returned as a large JSON object but the part we’re interested in is stored in the key called resultTable. It contains the names of the columns returned, the values of the columns, and their datatypes. The following shows the result returned for the query that we’ve submitted above.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

{
  "dataSchema": {
    "columnNames": [
      "user_agent"
    ],
    "columnDataTypes": [
      "STRING"
    ]
  },
  "rows": [
    [
      "Mozilla/5.0 (Android 8.1.0; Mobile; rv:123.0) Gecko/123.0 Firefox/123.0"
    ]
  ]
}

We’ll now look at writing SQL queries using the query console. Let’s write a SQL query which counts the number of orders placed each day. To do this, we’d have to convert the created_at column from milliseconds to date and then run a group by to find the count of the orders that have been placed. The following query gives us the desired result.

1
2
3
4
5
6

SELECT
    TODATETIME(created_at, 'yyyy-MM-dd') AS dt,
    COUNT(*) AS count
FROM orders
GROUP BY 1
ORDER BY 1 ASC;

We can run this in the console using the single-stage engine since it is one of the simpler queries. To do this, we’ll paste the query in the query console and leave the “Use Multi-Stage Engine” checkbox unchecked. The result of running the query is shown in the screenshot below.

We’ll now modify the query so that it requires the multi-stage engine. Using features of SQL language like window functions, common table expressions, joins, etc. requires executing the query using the multi-stage engine. We’ll write a query which finds the top five user agents and ranks them. This requires using common table expressions, and window functions and is the perfect candidate for using the multi-stage engine. The query is shown below.

1
2
3
4
5
6
7
8
9
10
11
12

WITH ua AS (
    SELECT
        user_agent,
        COUNT(*) AS count,
        RANK() OVER (ORDER BY COUNT(*) DESC) AS rank
    FROM orders
    GROUP BY 1
)
SELECT user_agent, count
FROM ua
WHERE rank <= 5
ORDER BY rank;

The result of running this query is shown below. Notice how the checkbox to use the multi-stage engine is checked.

Having seen how to query Pinot using the API, and the query console with either single-stage or multi-stage engine, we’ll move on to querying Pinot using Trino. We’ll begin by connecting to Trino using its CLI utility and create a catalog which connects to our Pinot instance. Then, we’ll run queries using Trino. We’ll also see how we can leverage query federation provided by Trino to connect to AWS Glue and create views and tables on top of the data stored in Pinot.

Let’s start by connecting to Trino. The following command shows how to connect to the Trino instance running as a Docker container using its command-line utility. You can follow the instructions mentioned in the official documentation to setup the CLI.

1

./trino http://localhost:9080

Every database in Trino that we’d like to connect to is configured using a catalog. A catalog is a collection of properties that specify how to connect to the database. We’ll begin by creating a catalog which allows us to query Pinot.

1
2
3
4

CREATE CATALOG pinot USING pinot
WITH (
    "pinot.controller-urls" = 'pinot-controller:9000'
);

The CREATE CATALOG command creates a catalog. It takes the name of the catalog, which we’ve specified as pinot, and the name of the connector which connects to the database, which we’ve also specified as pinot. The WITH section specifies properties that are required to connect to the database. We’ve specified the URL of the controller. Once the catalog is created, we can begin querying the tables in the database. The tables in Pinot are stored in the default schema of the pinot connector. To be able to query these, we’ll have to USE the catalog and schema. The following command sets the schema for the current session.

1

USE pinot.default;

To view the tables in the current schema, we’ll execute the SHOW TABLES command.

1
2
3
4
5

trino:default> SHOW TABLES;
 Table
--------
 orders
(1 row)

Let’s build upon the query that we wrote previously which calculates the count of the orders placed on a given day. Let’s say we’d like to find the percentage change between the number of orders placed on a given day and the day prior. We can do this using the LAG window function which will allow us to access the value of the prior row. The following query shows how to calculates this.

1
2
3
4
5
6
7
8
9
10
11
12
13
14

WITH FUNCTION div(x DOUBLE, y DOUBLE)
  RETURNS DOUBLE
  RETURN x / y
WITH ua AS (
  SELECT CAST(FROM_UNIXTIME(created_at / 1e3) AS DATE) AS dt,
         COUNT(*) AS count
  FROM orders
  GROUP BY 1
)
SELECT dt,
       count,
       LAG(count, 1) OVER (ORDER BY dt ASC) AS prev_count,
       ROUND(DIV(count,  LAG(count, 1) OVER (ORDER BY dt ASC)), 2) AS pct
FROM ua;

There’s a lot going on in the query above so let’s break it down. We begin by defining an inline function called DIV which performs division on two numbers. The reason for writing this function is that the division operator in Pinot returns the integer part of the quotient. To get the quotient as a decimal, we’d have to cast the values to DOUBLE. The function does just that. In the common table expression, we calculate the number of orders placed each day. Finally, in the SELECT statement, we find the number of orders placed on the day prior using the LAG window function.

Running the query gives us the following result.

1
2
3
4
5

     dt     | count | prev_count | pct
------------+-------+------------+------
 2024-12-29 | 11610 |       NULL | NULL
 2024-12-30 | 13849 |      11610 | 1.19
 2024-12-31 | 13649 |      13849 | 0.99

Let’s now say that we’d like to run the query frequently. Perhaps we’d like to display the table in a visualization tool. One way to do this would be to store the query as a view. However, Pinot does not support views. We’d have to work around this by relying on Trino’s query federation to write the result to another data store which supports creating views. For the sake of this post, we’ll use AWS Glue as a replacement for HDFS.

Let’s start with creating a Hive catalog in which we use S3 as the backing store.

1
2
3
4
5
6
7
8
9
10
11
12

CREATE CATALOG hive USING hive
WITH (
    "hive.metastore" = 'glue',
    "hive.recursive-directories" = 'true',
    "hive.storage-format" = 'PARQUET',
    "hive.insert-existing-partitions-behavior" = 'APPEND',
    "fs.native-s3.enabled" = 'true',
    "s3.endpoint" = 'https://s3.us-east-1.amazonaws.com',
    "s3.region" = 'us-east-1',
    "s3.aws-access-key" = '...',
    "s3.aws-secret-key" = '...'
);

In the query above, we’re creating the Hive catalog which we’ll use to create and store datasets. Since we’re storing files in S3, we need to specify the region and its S3 endpoint. You’d have to replace the keys with those of your own if you’re running the example locally.

Once we create the catalog, we’ll have to create the schema where datasets will be stored. Schemas are created with CREATE SCHEMA command and require that we provide a path in an S3 bucket where the files will be stored. The query below shows how to create a schema named views.

1
2
3
4

CREATE SCHEMA hive.views
WITH (
    "location" = 's3://apache-pinot-hive/views'
);

Once the schema is created, we can persist the query or its results for quicker access. In the query that follows, we create a view on top of Pinot.

1
2
3
4
5
6
7
8
9
10
11
12

CREATE VIEW hive.views.daily_orders AS
WITH ua AS (
  SELECT CAST(FROM_UNIXTIME(created_at / CAST(1e3 AS DOUBLE)) AS DATE) AS dt,
         COUNT(*) AS count
  FROM pinot.default.orders
  GROUP BY 1
)
SELECT dt,
       count,
       LAG(count, 1) OVER (ORDER BY dt ASC) AS prev_count,
       ROUND(CAST(count AS DOUBLE) / LAG(count, 1) OVER (ORDER BY dt ASC), 2) AS pct
FROM ua;

We can query the view once it is created. This allows us to save the queries so that they can be referenced in data visualization tools. In the view above, we’ll get the realtime difference between orders placed since Pinot will be queried every time we select from the view. A small caveat to note is that views cannot store inline functions so we had to cast one of the operands in the division operation to double manually.

To see this in action, we’ll run the data generation script one more time and then query the view. We can see that the counts for orders placed today, yesterday, and day before yesterday increase after the script runs.

1
2
3
4
5
6
7
8

trino> SELECT * FROM hive.views.daily_orders;
     dt     | count | prev_count | pct
------------+-------+------------+------
 2024-12-29 | 11610 |       NULL | NULL
 2024-12-30 | 13849 |      11610 | 1.19
 2024-12-31 | 26281 |      13849 |  1.9
 2025-01-01 | 15033 |      26281 | 0.57
 2025-01-02 | 12266 |      15033 | 0.82

Creating views like this provides us with a way to save queries that we’d like to run frequently. As we’ll see in later posts, these can also be referenced in data visualization tools to provide realtime analytics.

That’s it on how to run SQL on Pinot.

In the previous post we looked at evolving the schema. We briefly discussed handling null values in columns when we added the user_agent column. It allows null values since enableColumnBasedNullHandling is set to true. However, we weren’t able to see nullability in action since that column always had values in it. In this post we’ll evolve the schema one more time and add columns that have null values in them. We’ll see how to handle null values in Pinot queries, and how they differ from nulls in other databases. Let’s dive right in.

Getting started

We’ll begin by looking at the source payload that we’ve stored in Pinot.

1
2
3
4
5
6
7
8
9

{
    "user_id": 4,
    "cafe_id": 27,
    "address_id": 4,
    "created_at": 1735211553094,
    "id": 1,
    "user_agent": "Mozilla/5.0 (Windows NT 10.0; Win64; x64) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/121.0.0.0 Safari/537.36 Edg/121.0.0.0",
    "status": 0
}

In the payload above, we notice that there’s created_at but no updated_at or deleted_at. That’s because these have null values in the source table in Postgres. Let’s update the schema and table definitions to store these fields.

To update the schema, we’ll add the following to dateTimeFieldSpecs.

1
2
3
4
5
6
7
8
9
10
11
12
13
14

{
  "name": "updated_at",
  "dataType": "LONG",
  "format": "1:MILLISECONDS:EPOCH",
  "granularity": "1:MILLISECONDS",
  "defaultNullValue": "-1"
},
{
  "name": "deleted_at",
  "dataType": "LONG",
  "format": "1:MILLISECONDS:EPOCH",
  "granularity": "1:MILLISECONDS",
  "defaultNullValue": "-1"
}

In the JSON above, we specify the usual fields just as we did for created_at. We also set defaultNullValue. This value will be used instead of null when these fields are extracted from the source payload. This is different from what you’d usually observe in a database that supports null values. The reason for this is that Pinot uses a forward index to store the values of each column. This index does not support storing null values and instead requires that a value be provided which will be stored in place of null. In our case, we’ve specified -1. The value that we specify as a default must be of the same data type as the the column. Since the two fields are of type LONG, specifying -1 suffices.

We’ll PUT this schema using the following curl command.

1

curl -XPUT -F schemaName=@tables/002-orders/orders_schema.json localhost:9000/schemas/orders | jq .

Next, we’ll update the table definition by adding a couple of field-level transformations.

1
2
3
4
5
6
7
8

{
    "columnName": "updated_at",
    "transformFunction": "jsonPath(source, '$.updated_at')"
},
{
    "columnName": "deleted_at",
    "transformFunction": "jsonPath(source, '$.deleted_at')"
}

And POST it using the following curl command.

1

curl -XPUT -H 'Content-Type: application/json' -d @tables/002-orders/orders_table.json localhost:9000/tables/orders | jq .

Like we did last time, we’ll reload all the segments using the following curl command.

1

curl -XPOST localhost:9000/segments/orders/reload | jq .

Now when we open the query console, we’ll see the table with updated_at and deleted_at fields with their values set to -1.

We know that we have a total of 5000 rows where the deleted_at field is set to null. This can be verified by running a count query in Pinot. This shows that although the values in the column are set to -1, Pinot identifies them as null and returns the correct result.

1
2
3

SELECT COUNT(*)
FROM orders
WHERE deleted_at IS NULL;

A workaround suggested in the documentation is to use comparison operators to compare against the value used in place of null. For example, the following query will produce the same result as the one shown above.

1
2
3

SELECT COUNT(*)
FROM orders
WHERE deleted_at = -1;

That’s it on how to handle null values in Pinot.

In the previous post we saw how to ingest the data into Pinot using Debezium. In this post we’re going to see how to evolve the schema of the tables stored in Pinot. We’ll begin with a simple query which computes an aggregate on the user agent column stored within the source payload. Then, we’ll extract the value of user agent column out of the source payload into a column of its own.

Getting started

Let’s start with a simple query. Let’s count the number of times each user agent appears in the table and sort it in descending order. We can do this using the following SQL query.

1
2
3
4
5

SELECT JSON_EXTRACT_SCALAR(source, '$.user_agent', 'STRING', '...') AS user_agent,
       COUNT(*) AS count
FROM orders
GROUP BY 1
ORDER BY 2 DESC;

The result of running this query is shown below.

Let’s take a closer look at the query. To extract values out of the source column, we use the JSON_EXTRACT_SCALAR() function. It takes the name of the column containing the JSON payload, the path of the value within the payload, the datatype of the value returned, and the value to be used as a replacement for null.

For a simple query like this, using JSON_EXTRACT_SCALAR() works. However, it becomes unwieldy when there are more than one column to extract or when writing ad-hoc business analytics queries that join multiple tables on values present within a JSON column. Writing SQL would be easier if we could extract the value out of the JSON payload into a column of its own.

To extract the values out of the source payload into its own column, we’ll have to update the schema and table definitions. We’ll update the schema definition to add new columns, and we’ll update the table definition to extract fields out of the source column using field-level transformations.

Let’s begin by updating the schema.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33

{
  "schemaName": "orders",
  "enableColumnBasedNullHandling": true,
  "dimensionFieldSpecs": [
    {
      "name": "id",
      "dataType": "STRING",
      "notNull": true
    },
    {
      "name": "source",
      "dataType": "JSON",
      "notNull": true
    },
    {
      "name": "user_agent",
      "dataType": "STRING"
    }
  ],
  "dateTimeFieldSpecs": [
    {
      "name": "created_at",
      "dataType": "LONG",
      "format": "1:MILLISECONDS:EPOCH",
      "granularity": "1:MILLISECONDS",
      "notNull": true
    }
  ],
  "primaryKeyColumns": [
    "id"
  ],
  "metricFieldSpecs": []
}

We’ve added user_agent as a new column under dimensionFieldSpecs. Notice that we’ve set enableColumnBasedNullHandling to true. This allows columns to store null values in them. In Pinot, allowing or disallowing null values is configured per-table. The recommended way is to use column-based null handling where each column is configured to allow or disallow null values. This is what we’ve used in our schema above. The id, source, and created_at columns do not allow null values in them since they have notNull set to true. The user_agent column allows null values in it since it is implicitly nullable.

We’ll PUT the updated schema using curl.

1

curl -XPUT -F schemaName=@tables/002-orders/orders_schema.json localhost:9000/schemas/orders | jq .

Upon opening the query console we find that there’s an error message. This message indicates that the segments are invalid because they were created using an older version of the schema. We can reload all the segments to fix this error but we’ll get to that in a minute. We’ll first update the table definition.

To update the table definition, we’ll add the following field-level transformation to the transformConfigs.

1
2
3
4

{
  "columnName": "user_agent",
  "transformFunction": "jsonPath(source, '$.user_agent')"
}

In this transformation we’re extracting the user_agent field into a column with the same name. Notice how we’re referencing the source column instead of the payload emitted by Debezium to get the value. Once we’ve made this change we’ll PUT the new table definition using curl.

1

curl -XPUT -H 'Content-Type: application/json' -d @tables/002-orders/orders_table.json localhost:9000/tables/orders | jq .

Finally, we’ll reload all the segments for this table using the following curl command.

1

curl -XPOST localhost:9000/segments/orders/reload | jq .

Upon opening the query console, we find that the a new user_agent column has been added to the table.

It’s common for the table to change with time as new columns are added. Consequently, the schema and table definitions will evolve in Pinot. As we update the schema in Pinot, we have to keep in mind that columns can only be added and not removed. In other words, the schema needs to remain backwards compatible. If you’d like to drop a column or rename it, you’ll have to recreate the table.

That’s it for how to evolve schema in Pinot.

In the first part we saw the overall design of the system. In the second part we created a dataset that we can work with. In this post we’ll look at the first category of components and these are the ones that bring the data into the platform. We’ll see how we can stream data from the database using Debezium and store it in Pinot realtime tables.

Before we begin

The setup is still Dockerized and now has containers for Debezium, Kafka, and Pinot. In a nutshell, we’ll stream data from the Postgres instance into Kafka using Debezium and then write it to Pinot tables.

Getting started

In the first part of the series we briefly looked at Debezium. To recap, Debezium is a platform for change data capture. It consists of connectors which capture change data from the database and emit them as events into Kafka. Which database tables to monitor and which Kafka topic to write them to are specified as a part of the connector’s configuration. This configuration is written as a JSON object and sent to a specfic endpoint to spawn a new connector.

We’ll begin by creating configuration for a connector which will monitor all the tables in the database and route each of them to a dedicated Kafka topic.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26

{
    "name": "order_service",
    "config": {
        "connector.class": "io.debezium.connector.postgresql.PostgresConnector",
        "database.hostname": "db",
        "database.user": "postgres",
        "database.password": "my-secret-pw",
        "database.dbname": "postgres",
        "database.server.name": "postgres",
        "plugin.name": "pgoutput",
        "publication.autocreate.mode": "filtered",
        "time.precision.mode": "connect",
        "tombstones.on.delete": "false",
        "snapshot.mode": "no_data",
        "heartbeat.interval.ms": "1000",
        "transforms": "route",
        "transforms.route.type": "org.apache.kafka.connect.transforms.RegexRouter",
        "transforms.route.regex": "([^.]+)\\.([^.]+)\\.([^.]+)",
        "transforms.route.replacement": "$3",
        "event.processing.failure.handling.mode": "skip",
        "producer.override.compression.type": "snappy",
        "signal.data.collection": "debezium.signal",
        "topic.prefix": "microservice",
        "decimal.handling.mode": "float"
    }
}

There are two main parts to this configuration - name and config. The name is the name we’ve given to the connector. The config contains the actual configuration of the connector. We specify quite a few things in the config object. We specify the class of the connector which is the fully qualified name of the Java class, the credentials to connect to the database, whether or not to take a snapshot, how to route the data to the appropriate Kafka topics, and how to pass signals to Debezium.

While most of the configuration is self-explanatory, we’ll look closely at the ones related to snapshot, signalling, and routing. We set the snapshot mode to no_data which means that the connector will stream historical rows from the database. The only rows that will be emitted are the ones created or updated after the connector began running. We’ll use this setting in conjunction with signals to incrementally snapshot the tables we’re interested in. Signals are a way to modify the behavior of the connector, or to trigger a one-time action like taking an ad-hoc snapshot. When we combine no_data with signals, we can tell Debezium to selectively snapshot the tables we’re interested in. The signal.data.collection property specifies the name of the table which the connector will monitor for any signals that are sent to it.

Finally, we specify a route transform. We do this by writing a regex which matches against the fully qualified name of the table, and extracts only the table name. This allows us to send the data from every table into a dedicated Kafka topic of its own.

Notice how we’ve not specified which tables to monitor. Since it is a Postgres database, the connector will monitor all the tables in all the schemas within the database and stream them. Now that the configuration is created, we’ll POST it to the appropriate endpoint to create the connector.

1

curl -H "Content-Type: application/json" -XPOST -d @tables/002-orders/debezium.json localhost:8083/connectors | jq .

Now that the connector is created, we will signal it to initiate a snapshot. Signals are sent to the connector using rows inserted into the table. We’ll execute the following INSERT query to tell the connector to take a snapshot of the orders table.

1
2
3
4
5
6

INSERT INTO debezium.signal
VALUES (
    gen_random_uuid()::TEXT,
    'execute-snapshot',
    '{"data-collections": [".*\\.orders"], "type": "incremental"}'
);

The row tells the connector to initiate a snapshot, as indicated by execute-snapshot, and stream historical rows from the orders table in all the schemas within the database. It is an incremental snapshot so it will happen in batches. If we docker exec into the Kafka container and use the console consumer, we’ll find that all the rows eventually get streamed to the topic. The command to show it is given below.

1
2

[kafka@kafka ~]$ kafka-console-consumer.sh --bootstrap-server kafka:9092 --topic orders --from-beginning | wc -l
^CProcessed a total of 5000 messages

We can compare this with the row count in the table using the following SQL command.

1
2
3
4

SELECT COUNT(*) FROM public.orders;
| count |
|-------|
|  5000 |

Now that the data is in Kafka, we’ll move on to how to stream it into a Pinot table. Before we get to that, we’ll look at what a table and schema are in Pinot.

A table in Pinot is similar to a table in a relational database. It has rows and columns where each column has a datatype. Tables are where data is stored in Pinot. Every table in Pinot has an associated schema and it is in the schema where the columns and their datatypes are defined. Tables can be realtime, where they store data from a streaming source such as Kafka. They can be offline, where they load data from batch sources. Or they can be hybrid, where they load data from both a batch source and a streaming source. Both the schema and table are defined as JSON.

Let’s start by creating the schema.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26

{
  "schemaName": "orders",
  "enableColumnBasedNullHandling": true,
  "dimensionFieldSpecs": [
    {
      "name": "id",
      "dataType": "STRING"
    },
    {
      "name": "source",
      "dataType": "JSON"
    }
  ],
  "dateTimeFieldSpecs": [
    {
      "name": "created_at",
      "dataType": "LONG",
      "format": "1:MILLISECONDS:EPOCH",
      "granularity": "1:MILLISECONDS"
    }
  ],
  "primaryKeyColumns": [
    "id"
  ],
  "metricFieldSpecs": []
}

The schema defines a few things. It defines the name of the schema. This will also become the name of the table. Next, it defines the fields that will be present in the table. We’ve defined id, source, and created_at. The first two are specified in dimensionFieldSpecs and specify a column which becomes a dimension for any metric. The created_at field is specified in dateTimeFieldSpecs since it specifies a time column; Debezium will send timestamp columns as milliseconds since epoch. We’ve specified id as the primary key. Finally, enableColumnBasedNullHandling allows columns to have null values in them.

Once the schema is defined, we can create the table configuration.

The configuration of tbe table is more involved than the schema so we’ll go over it one key at a time. We begin by specifying the tableName as “orders”. This matches the name of the schema. We specify tableType as “REALTIME” since the data we’re going to ingest comes from a Kafka topic. The query key specifies properties related to query execution. The segmentsConfig key specifies properties related to segments like the time column to use for creating a segment. The tenants key specifies the tenants for this table. A tenant is a logical namespace which restricts where the cluster processes queries on the table. The tableIndexConfig defines the indexing related information for the table. The metadata key specifies the metadata for this table. The upsertCconfig key specifies configuration for upserting into the table. The ingestionConfig key defines where we’d be ingesting data from and what field-level transformations we’d like to apply. The routing key defines properties that determine how the broker selects the servers to route.

The part of the configuration we’ll specifically look at is the ingestionConfig and upsertConfig. First, ingestionConfig.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37

{
  "ingestionConfig": {
    "streamIngestionConfig": {
      "streamConfigMaps": [
        {
          "realtime.segment.flush.threshold.rows": "0",
          "stream.kafka.decoder.prop.format": "JSON",
          "key.serializer": "org.apache.kafka.common.serialization.ByteArraySerializer",
          "stream.kafka.decoder.class.name": "org.apache.pinot.plugin.stream.kafka.KafkaJSONMessageDecoder",
          "streamType": "kafka",
          "value.serializer": "org.apache.kafka.common.serialization.ByteArraySerializer",
          "stream.kafka.consumer.type": "LOWLEVEL",
          "realtime.segment.flush.threshold.segment.rows": "50000",
          "stream.kafka.broker.list": "kafka:9092",
          "realtime.segment.flush.threshold.time": "3600000",
          "stream.kafka.consumer.factory.class.name": "org.apache.pinot.plugin.stream.kafka20.KafkaConsumerFactory",
          "stream.kafka.consumer.prop.auto.offset.reset": "smallest",
          "stream.kafka.topic.name": "orders"
        }
      ]
    },
    "transformConfigs": [
      {
        "columnName": "id",
        "transformFunction": "jsonPath(payload, '$.after.id')"
      },
      {
        "columnName": "source",
        "transformFunction": "jsonPath(payload, '$.after')"
      },
      {
        "columnName": "created_at",
        "transformFunction": "jsonPath(payload, '$.after.created_at')"
      }
    ]
  }
}

In the ingestionConfig we specify the the Kafka topics to read from. In the snippet above, we’ve specified the “orders” topic. We also specify field-level transformations in transformConfigs. Here we extract the id, source, and created_at fields from the JSON payload generated by Debezium.

With the schema and table defined, we’ll POST them to the appropriate endpoints using curl. The following two commands create the schema followed by the table.

1
2

curl -F schemaName=@tables/002-orders/orders_schema.json localhost:9000/schemas | jq .
curl -XPOST -H 'Content-Type: application/json' -d @tables/002-orders/orders_table.json localhost:9000/tables | jq .

Once the table is created, it will begin ingesting data from the “orders” Kafka topic. We can view this data by opening the Pinot query console. Notice how the source column contains the entire “after” payload generated by Debezium.

That’s it. That’s how to stream data using Debezium into Pinot.

In the previous post we saw the overall design of the platform. We saw how the components of the system are divided into three separate categories: those that bring the data in, those that create datasets on this data, and those that display visualizations. Starting from this post, we’re going to start building the system. We’ll work with the data of a fictitious online cafe that we’ll populate using a Python script. In subsequent posts, we’ll ingest this data into the platform and create visualizations on top of it.

Before we begin

The setup, for this post, consists of a Docker container for Postgres which is a part of the compose file. We’ll bring up the container before we begin populating the database.

The data

We’ll create and populate a table which stores the orders placed by the customer. The table contains, among other fields, the id of the user who placed the order, the id of the address where the order needs to be delivered, the status of the order, and the user agent of the device used to place the order. The code snippet below shows how the model is represented as a Python class.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17

class Order(peewee.Model):
    """An order placed by the customer."""

    class Meta:
        table_name = "orders"
        database = database

    id = peewee.BigAutoField()
    user_id = peewee.IntegerField()
    address_id = peewee.IntegerField()
    cafe_id = peewee.IntegerField()
    partner_id = peewee.IntegerField(null=True)
    created_at = peewee.DateTimeField(default=datetime.datetime.now)
    updated_at = peewee.DateTimeField(null=True)
    deleted_at = peewee.DateTimeField(null=True)
    status = peewee.IntegerField(default=0)
    user_agent = peewee.TextField()

Once we’ve created this class, we’ll write a function which creates instances of this class and persists them in the database. There are classes representing the cafe, the addresses saved by the user, and the delivery partner who will be assigned to deliver the order. However, these have been left out for the sake of brevity. The code snippet below shows this function.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29

def create_orders(
    users: list[User],
    addresses: list[Address],
    cafes: list[Cafe],
    partners: list[Partner],
    n: int = 100,
) -> list[Order]:
    ua = UserAgent()
    orders = []

    def base_order() -> dict:
        cafe = cafes[random.randint(0, len(cafes) - 1)]
        user = users[random.randint(0, len(users) - 1)]
        addr = [_ for _ in addresses if _.user_id == user.id][0]
        user_agent = ua.random

        return {
            "user_id": user.id,
            "address_id": addr.id,
            "cafe_id": cafe.id,
            "user_agent": user_agent,
        }

    for _ in range(n):
        data = {**base_order(), "status": OrderStatus.PLACED.value}
        order = Order.create(**data)
        orders.append(order)

    return orders

Once we have all our classes and functions in place, we’ll run the script which populates the data.

1

python faker/data.py

We can now query the database to see our data.

This is it for the second part of the series.

I’d previously written about creating a data platform using Pinot, Trino, Airflow, and Debezium. It was a quick how-to that showed how to glue the pieces together to create a data platform. In this post we’ll go deeper into the design of the system and look at building the system in the posts that follow.

The design

A common requirement for data engineering teams is to move data stored within the databases owned by various microservices into a central data warehouse. One of the ways to move this data is by loading it incrementally. In this approach, once the data has been loaded fully, subsequent loads are done in smaller increments. These contain rows that have changed since the last time the warehouse was loaded. This brings the data into the warehouse periodically as the loads are run on a specified schedule.

Recently the shift has been towards moving data in realtime so that analytics can be derived quickly. Change data capture allows capturing row-level changes as they happen as a result of inserts, updates, and deletes in the tables. Responding to these events allows us to load the warehouse in realtime.

The diagram below shows how we can combine Pinot, Trino, Airflow, Debezium, and Superset to create a realtime data platform.

The components of the system can be divided into three broad categories. The first category is those that bring data into the platform and are shown in dark green. This category consists of the source database system, Debezium, and Pinot. Debezium reads the stream of changes happening in the database and writes them into Pinot. The second category is those that create datasets on top of the data ingested into Pinot and are shown in dark grey. This category consists of Airflow, Trino, and HDFS. Airflow uses Trino to create tables and views in HDFS on top of the data stored in Pinot. Finally, the last category is those that consume the datasets and present them to the end user. This category consists of data visualization tools like Superset.

Let’s discuss each of these components in more detail.

Debezium is a platform for change data capture. It consists of connectors which monitor the database tables for inserts, updates, and deletes and emit events into Kafka. These events can then be written into the data warehouse to create an up-to-date version of the table in the upstream database. We’ll run Debezium as a Docker container. When run like this, the connectors are available as a part of the image and can be configured using a REST API. To configure the connector we’ll send a JSON object to a specific endpoint. This object contains information such as the credentials of the database, the databases or tables we’d like to monitor, any transformations we’d like to apply to this data, and so on. As we’ll see when we begin building the system, we can monitor all of our tables for changes happening in them.

Pinot is an OLAP datastore that is built for real-time analytics. It supports creating tables that consume data in realtime so that insights can be derived quickly. Pinot, when combined with Debezium, allows us to ingest row-level changes as they happen in the source table. Configurations for Pinot tables and schemas are written in JSON and sent to their respective endpoints to create them. We’ll create a realtime table which ingests events emitted by Debezium. Using the upsert functionality provided by Pinot, we’ll keep only the latest state of the row in the table. This makes it easier to to create reports or do ad-hoc analysis.

Trino provides query federation by allowing us to query multiple data sources with a unified SQL interface. It is fast and distributed which means we can use it to query large amounts of data. We’ll use it in conjunction with Pinot since the latter does not yet provide full SQL capabilities. Trino allows connecting to a database by creating a catalog. As we can see from the diagram, we’ll need two catalogs - Pinot and HDFS. Since it is currently not possible to create views, materialized views, or tables from select statements in Pinot, we’ll create them in HDFS using Trino. This allows us to speed up the reports and dashboards since all of the required data will be precomputed and available in HDFS as either a materialized view or a table.

Airflow is an orchestrator that allows creating complex workflows. These workflows are created as Python scripts that define a directed acyclic graph (DAG) of tasks. Airflow then schedules these tasks for execution at defined intervals. Tasks are defined using operators. For example, to execute a Python function one would use the PythonOperator. Similarly, there are operators to execute SQL queries. We’ll use these operators to query Trino and create the datasets that are needed for reporting and dashboards. Peridocially regenerating these datasets would allow us to provide reports that present the latest data.

Superset is a data visualization tool. We’ll connect Superset to Trino so that we can visualize the datasets that we’ve created in HDFS.

Having discussed the various components of the design, let’s look at the design goals it achieves. First, the system is designed to be realtime. With change data capture using Debezium, we can respond to every insert, update, and delete happening in the source table as soon as it happens. Second, the system is designed with open-source technologies. This allows us to benefit from the experience of the collaborators and community behind each of these projects. Finally, the system is designed to be as close to self-service as possible. As we’ll see, the design of the system reduces the dependency of the of the downstream business analytics and data scientist teams on the data engineering team significantly.

This is it for the first part of the series.

I’d previously written about property-based testing in Clojure. In this blog post I’d like to talk about how we can do the same in Python using the Hypothesis library. We’ll begin with a quick recap of what property-based testing is, and then dive head-first into writing some tests.

What is property-based testing?

Before we get into property-based testing, let’s talk about how we usually write tests. We provide a known input to the code under test, capture the resulting output, and write an assertion to check that it matches our expectations. This technique of writing tests is called example-based testing since we provide examples of inputs that the code has to work with.

While this technique works, there are some drawbacks to it. Example-based tests take longer to write since we need to come up with examples ourselves. Also, it’s possible to miss out on corner cases.

In contrast, property-based testing allows us to specify the properties of the code and test that they hold true under a wide range of inputs. For example, if we have a function f that takes an integer and performs some computation on it, a property-based test would test it for positive integers, negative integers, very large integers, and so on. These inputs are generated for us by the testing framework and we simply need to specify what kind of inputs we’re looking for.

Having briefly discussed what property-based testing is, let’s write some code.

Writing property-based tests

Testing a pure function

Let’s start with a function which computes the n’th Fibonacci number.

1
2
3
4
5
6
7
8
9

@functools.cache
def fibonacci(n: int) -> int:
    """
    Computes the nth number in the Fibonacci sequence.
    """
    if n <= 1:
        return n

    return fibonacci(n - 1) + fibonacci(n - 2)

The sequence of numbers goes 0, 1, 1, 2, 3, etc. We can see that all of these numbers are greater than or equal to zero. Let’s write a property-based test to formalize this.

1
2
3
4
5
6
7

from hypothesis import given, strategies as st
from functions import fibonacci


@given(st.integers())
def test_fibonacci(n):
    assert fibonacci(n) >= 0

In the code snippet above, we’ve wrapped our test using the @given decorator. This makes it a property-based test. The argument to the decorator is a search strategy. A search strategy generates random data of a given type for us. Here we’ve specified that we need integers. We can now run the test using pytest as follows.

1

PYTHONPATH=. pytest .

The test fails with the following summary.

1

FAILED test/functions/test_fibonacci.py::test_fibonacci - ExceptionGroup: Hypothesis found 2 distinct failures. (2 sub-exceptions)

When looking at the logs, we find that the first failure is because the maximum recursion depth is reached when the value of n is large.

1
2
3

n = 453
... lines omitted ...
RecursionError: maximum recursion depth exceeded

The second failure is because the function returned a negative integer when the value of n is negative; in this case it is n=-1. This violates our assertion that the numbers in the Fibonacci sequence are non-negative.

1
2
3
4
5
6
7
8
9
10

+---------------- 2 ----------------
| Traceback (most recent call last):
|   File "/Users/fasih/Personal/pytesting/test/functions/test_fibonacci.py", line 8, in test_fibonacci
|     assert fibonacci(n) >= 0
| AssertionError: assert -1 >= 0
|  +  where -1 = fibonacci(-1)
| Falsifying example: test_fibonacci(
|     n=-1,
| )
+------------------------------------

To remedy the two failures above, we’ll add an assertion at the top of the function which will ensure that the input n is in some specified range. The updated function is given below.

1
2
3
4
5
6
7
8
9
10
11

@functools.cache
def fibonacci(n: int) -> int:
    """
    Computes the nth number in the Fibonacci sequence.
    """
    assert 0 <= n <= 300, f"n must be between 0 and 300; {n} was passed."

    if n <= 1:
        return n

    return fibonacci(n - 1) + fibonacci(n - 2)

We’ll update our test cases to reflect this change in code. The first test case checks the function when n is between 0 and 300.

1
2
3

@given(st.integers(min_value=0, max_value=300))
def test_fibonacci(n):
    assert fibonacci(n) >= 0

The second case checks when n is large. In this case we check that the function raises an AssertionError.

1
2
3
4

@given(st.integers(min_value=5000))
def test_fibonacci_large_n(n):
    with pytest.raises(AssertionError):
        fibonacci(n)

Finally, we’ll check the function with negative values of n. Similar to the previous test case, we’ll check that the function raises an AssertionError.

1
2
3
4

@given(st.integers(min_value=-2, max_value=-1))
def test_fibonacci_negative(n):
    with pytest.raises(AssertionError):
        fibonacci(n)

Testing persistent data

We’ll now use Hypothesis to generate data that we’d like to persist in the database. The snippet below shows a Person model with fields to store name and date of birth. The age property returns the current age of the person in years, and the MAX_AGE variable indicates that the maximum age we’d like to allow in the system is 120 years.

1
2
3
4
5
6
7
8
9
10
11
12
13
14

class Person(peewee.Model):

    MAX_AGE = 120

    class Meta:
        database = db

    id = peewee.BigAutoField(primary_key=True, null=False)
    name = peewee.CharField(null=False, max_length=120)
    dob = peewee.DateField(null=False)

    @property
    def age(self) -> int:
        return (datetime.date.today()).year - self.dob.year

We’ll add a helper function to create Person instances as follows.

1
2
3
4
5
6
7
8
9

def create(name: str, dob: datetime.date) -> Person:
    """
    Create a new person instance with the given name and date of birth.
    :param name: Name of the person.
    :param dob: Date of birth of the person.
    :return: A Person instance.
    """
    assert name, f"name cannot by empty"
    return Person.create(name=name, dob=dob)

Like we did for the function which computes Fibonacci numbers, we’ll add a test case to formalize this expectation. This time we’re generating random names and dates of birth and passing them to the helper function.

1
2
3
4
5
6
7

@given(
    text=st.text(min_size=1),
    dob=st.dates(),
)
def test_create_person(text, dob, create_tables):
    person = pr.create(name=text, dob=dob)
    assert 0 <= person.age <= Person.MAX_AGE

I’m persisting this data in a Postgres table and the create_tables fixture ensures that the tables are created before the test runs.

Upon running the test we find that it fails for two cases. The first case is when the input string contains a NULL character \x00. Postgres tables do not allow strings will NULL characters in them.

1
2
3
4
5
6

ValueError: A string literal cannot contain NUL (0x00) characters.
Falsifying example: test_create_person(
     create_tables=None,
     text='\x00',
     dob=datetime.date(2000, 1, 1),  # or any other generated value
)

The second case is when the date of birth is in the future.

1
2
3
4
5
6
7

AssertionError: assert 0 <= -1
  +  where -1 = <Person: 5375>.age
 Falsifying example: test_create_person(
     create_tables=None,
     text='0',  # or any other generated value
     dob=datetime.date(2025, 1, 1),
)

To remedy the first failure, we’ll have to sanitize the name input string that gets stored in the table. We’ll create a helper function which removes any NULL characters from the string. This will be called before name gets saved in the table.

1
2

def sanitize(s: str) -> str:
    return s.replace("\x00", "").strip()

To remedy the second failure, we’ll add an assertion ensuring that the age is less than or equal to 120. The updated create function is shown below.

1
2
3
4
5
6
7
8
9
10
11
12
13

def create(name: str, dob: datetime.date) -> Person:
    """
    Create a new person instance with the given name and date of birth.
    :param name: Name of the person.
    :param dob: Date of birth of the person.
    :return: A Person instance.
    """
    name = sanitize(name)

    assert name, f"name cannot by empty"
    assert 0 <= (datetime.date.today().year - dob.year) <= Person.MAX_AGE

    return Person.create(name=name, dob=dob)

We’ll update the test cases to reflect these changes. Let’s start by creating two variables that will hold the minimum and maximum dates allowed.

1
2

MIN_DATE = datetime.date.today() - datetime.timedelta(days=Person.MAX_AGE * 365)
MAX_DATE = datetime.date.today()

Next, we’ll add a test to ensure that we raise an AssertionError when the string contains only NULL characters.

1
2
3
4

@given(text=st.text(alphabet=["\x00"]))
def test_create_person_null_text(text, create_tables):
    with pytest.raises(AssertionError):
        pr.create(name=text, dob=MIN_DATE)

Next, we’ll add a test to ensure that dates cannot be in the future.

1
2
3
4
5
6
7

@given(
    text=st.text(min_size=1),
    dob=st.dates(min_value=MAX_DATE + datetime.timedelta(days=365)),
)
def test_create_person_future_dob(text, dob, create_tables):
    with pytest.raises(AssertionError):
        pr.create(name=text, dob=dob)

Similarly, we’ll add a test to ensure that dates cannot be more than 120 years in the past.

1
2
3
4
5
6
7

@given(
    text=st.text(min_size=1),
    dob=st.dates(max_value=MIN_DATE - datetime.timedelta(days=365)),
)
def test_create_person_past_dob(text, dob, create_tables):
    with pytest.raises(AssertionError):
        pr.create(name=text, dob=dob)

Finally, we’ll add a test to ensure that in all other cases, the function creates a Person instance as expected.

1
2
3
4
5
6
7
8
9
10

@given(
    text=st.text(min_size=5),
    dob=st.dates(
        min_value=MIN_DATE,
        max_value=MAX_DATE,
    ),
)
def test_create_person(text, dob, create_tables):
    person = pr.create(name=text, dob=dob)
    assert 0 <= person.age <= Person.MAX_AGE

The tests pass when we rerun them so we can be sure that the function behaves as expected.

Testing a REST API.

Finally, we’ll look at testing a REST API. We’ll create a small Flask app with an endpoint which allows us to create Person instances. The API endpoint is a simple wrapper around the create helper function and returns the created Person instance as a dictionary.

1
2
3
4
5
6
7
8
9
10

@api.route("/person", methods=["POST"])
def create_person():
    name = request.json["name"]

    dob = request.json["dob"]
    dob = parse(dob).date()

    person = pr.create(name, dob)

    return model_to_dict(person)

We’ll add a test to generate random JSON dictionaries which we’ll pass as the body of the POST request. The test is given below.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

@given(
    json=st.fixed_dictionaries(
        {
            "name": st.text(min_size=5),
            "dob": st.dates(min_value=MIN_DATE, max_value=MAX_DATE),
        }
    )
)
def test_create_person(json, test_client):
    response = test_client.post(
        "/api/person",
        json=json,
        headers={"Content-Type": "application/json"},
    )

    assert response.status_code == 200

Similar to the tests for create function, we test that the API returns a response successfully when the inputs are proper.

That’s it. That’s how we can leverage Hypothesis to test Python code. You’ll find the code for this post in the Github repository.
